AC HYDRAULIC HYDRAULIC WORKSHOP CRANE, PARALLEL LEGS, 0.55 TON

Gallery Picture 1 for AC HYDRAULIC HYDRAULIC WORKSHOP CRANE, PARALLEL LEGS, 0.55 TON
Image for AC HYDRAULIC HYDRAULIC WORKSHOP CRANE, PARALLEL LEGS, 0.55 TON Image for AC HYDRAULIC HYDRAULIC WORKSHOP CRANE, PARALLEL LEGS, 0.55 TON Image for AC HYDRAULIC HYDRAULIC WORKSHOP CRANE, PARALLEL LEGS, 0.55 TON Image for AC HYDRAULIC HYDRAULIC WORKSHOP CRANE, PARALLEL LEGS, 0.55 TON

AC HYDRAULIC HYDRAULIC WORKSHOP CRANE, PARALLEL LEGS, 0.55 TON

Model # WJN5 Find distributor

Hydraulic workshop crane with parallel legs for pallets

  • Foldable within seconds for quick and easy storage
  • When folded the crane takes up a minimum of space on the workshop floor
  • Jib arm with large lifting capacity – even in 5th position
  • Hard chromium plated piston rod and pump piston for long life
  • Built-in safety overload valve
  • Fitted with 2 castors and 2 fixed wheels for easy manoeuvrability even with maximum load
  • Lifting hook pivots 360º
  • Hand operated dead man’s release for optimum safety whilst lowering

Technical data

  WJN5EUR
Capacity 1200 lbs
Lifting height 79.53 - 92.13 inches
Jib arm 37.60 - 54.13 inches
Frame height 4.92 inches
Frame length 55.91 inches
Height 59.84 inches
Inner width 39.39 inches
Frame width 43.31 inches
Weight 165 lbs
